Schmidt & Bender 1-8x24 PM-II ShortDot Dual CC riflescope MDR-T6 ret. RAL8000

$4,995.55
SKU:
SB6838454359282
UPC:
191992000106
Availability:
Special Order - contact Charlie's sales team for timeline and payment options

Schmidt & Bender 1-8x24 PM-II ShortDot Dual CC riflescope with MDR-T6 ret.

Superior dual focal plane CQBR / LPVO scope with Military MDR-T6 retical in RAL8000 color ST LT MTC ZC CCW

683-845-43E-K2-H2

Schmidtbender-1-8x-dual-cc-ral800

Note:  Inventory shows available to order, but that may or may not mean item is in stock.  This is a special order item with extended lead time, contact Charlie's sales team for for payment options, including refundable and non-refundable deposits

The 1-8x24 ShortDot from Schmidt & Bender is a feature rich riflescope line.  Combat ready LPVO, and sheer awesome civilian and law enforcement applications as well.  This is a true Close Quarter Battle Scope, and is used by many of the NATO forces for urban and close engagement. The patented CC mode integrates a true red dot sight. At 1.1x, turn to CC and the system becomes parallax free with 1x magnification for distances between 7 and 10 meters. With 8 different illumination increments, low-light shooting is a problem of the past. Schmidt & Bender is a name you can trust to deliver quality and reliable scopes.

The 1-8x24 PM II ShortDot Dual CC features a red dot in the 2nd focal plane, and an illuminable reticle at the 1st focal plane. This combines the advantage of both a reflex sight and a riflescope, which is an ideal solution for mobile use in urban terrain from short to medium distances.

The S&B 1-8x CC riflescope has a true 1x magnification and is parallax free to 7m. By increasing the magnification above the CC Mode the riflescope is parallax free to 100m. Since the FlashDot is located in the 2nd focal plane the size of the dot stays constant. Hereby three different illumination increments are eligible. At higher magnifications the Mildot reticle in the 1st focal plane can be used. Thus a opportunity for a direct measurement of target and object sizes is enabled. With a maximum magnification of 8 the 1-8x24 PM II ShortDot Dual CC is also an ideal riflescope for identification purposes and operations up to medium distances. Hereby the illumination of the reticle can be regulated in 8 different increments, whereof three are optimized for the usage with a night vision.

The 1-8x24 PM II ShortDot Dual CC has a FlashDot in the 2nd focal plane and an illuminable reticle at the 1st focal plane. This combines the advantage of both a reflex sight and a riflescope, which is an ideal solution for mobile use in urban terrain from short to medium distances. The FlashDot allows in combination with the CC Mode (Close Combat Mode) the usage as a reflex sight for short distances. In this mode the riflescope has a true 1 time magnification and is parallax free to 7m. By increasing the magnification above the CC Mode the riflescope is parallax free to 100m. Since the FlashDot is located in the 2nd focal plane the size of the dot stays constant. Hereby three different illumination increments are eligible. At higher magnifications the Mildot reticle in the 1st focal plane can be used. Thus a opportunity for a direct measurement of target and object sizes is enabled. With a maximum magnification of 8 the 1-8x24 PM II ShortDot Dual CC is also an ideal riflescope for identification purposes and operations up to medium distances. Hereby the illumination of the reticle can be regulated in 8 different increments, whereof three are optimized for the usage with a night vision.

With a weight of just 25 oz., a length of 11.54 inches and a 30mm main tube diameter the 1-8x24 PM II ShortDot Dual CC is compact 2-in-1 system.

This riflescope is in RAL8000, the German version of FDE or Coyote Brown is probably closer.  S&B offers the same scope in Pantone and Black.  If interested, ask your Charlie's Custom Clones team member.  RAL8000 has become a little more popular, especially with German rifles, like HK, but also with Knights Armament and LMT rifles and others.

Specifications

  • Scope Weight:  22.5 oz.
  • Scope Length:  11.54"
  • Magnification Range:  1-8x
  • Scope Objective Diameter:  24mm
  • Scope Tube Size / Mount:  30mm
  • Reticle Position:  Dual Focal Plane
  • Reticle Details:  MDR-T6 Reticle in 1st Focal Plane /  FlashDot in 2nd Focal Plane
  • Illuminated Reticle:  Yes
  • Scope Finish:  RAL8000
  • Scope Turret Rotation:  Counter Clockwise (CCW)
  • Turret Adjustment (Click Value):  1cm
  • Elevation Turret Details:  0 to 101cm
    ST LT MTC (Single Turn, Locking Turret, More Tactile Clicks)
  • Windage Turret Details: ST ZS LT (Single Turn; Zero Stop; Locking Turret)
    ±6 mrad
  • Parallax Adjustment:  100m Fix
  • Field of View:  35.3 - 4.9m / 100m
  • Exit Pupil:  9.8-3.0 mm
  • Eye Relief:  3.54"
  • Twilight Factor:  14.1 - 37.4
  • Light Transmission  >90%
