Stiller Mk13 Action for .300 WM - long action

$500.00 - $1,745.00
SKU:
STL9913110
Availability:
in stock and ships within 2 weeks if you can add to cart. Factory orders take 3 to 7 months
IN STOCK NOTE:
choice to add to cart, add name to waitlist, or make a desposit for future delivery

Stiller Mk13 .300WM action - right hand, no top rail

Mk13-Mo7

Long Action, as used on the Mk13 bolt action sniper rifle

Yes, this is the exact action used in USMC and Navy SEAL sniper rifles.

In 2010, Stiller was contacted by Naval Surface Warfare Center in Crane, Indiana. The Navy armory asked if there was interest in bidding on the MK13 Mod 7 project to supply custom actions for the Mod 7 version of the MK13 300 WinMag sniper platform. This was the first time the Navy considered using a custom action for a Mk13 platform. Stiller decided to compete and ultimately won the very difficult competition. After supplying five TAC 300 actions pulled at random from inventory, the Navy determined that the Stiller actions offered 100% parts interchangeability. For the first time in the history of the MK13, any part from any Stiller-based rifle could be interchanged with the same part on a different rifle with no change in function or accuracy.

Stiller Mk13 actions are black nitride coated and subject to a specially developed, rigorous QC process that holds our already industry-leading tolerances to within a half thousandth of an inch.

The Mk13 action comes standard in right-hand configuration and no top metal.  Special orders can be made for left-hand configuration and Picatinny rails in 0 or 20 MOA

Handcrafted from steel billet and head spaced and ready to add your barrel and chassis.  The Mk13 is the same footprint as the TAC-300.  The one piece bolt is fluted on the top and sides, but no fluting on the bottom, to assure no interference with magazine lips.  The Mk13 bolt is part of the TAC action series, and had a straight bolt handle.  The bolt knob is threaded and has a large bolt knob.  It is possible to install after market knobs to be swapped out by a gunsmith.

The M13 / TAC 300 action is a Remington 700 LA clone footprint, for purposes of selecting a chassis or stock, but any chassis top will need to be specific to Stiller TAC actions.



Highlights and specifications

  • Receiver Material: 416 Stainless hardened to 42 Rockwell
  • Receiver Length: 8.700”
  • Receiver Diameter: 1.35” (Remington 700)
  • Headspace: .700” Headspace tolerance is held to +/- .0005”
  • Bolt Design: 700” diameter
  • Bolt Stop: On side of receiver opposite bolt handle above the stock line
  • Bolt Throw: 90 degree
  • Bolt Material: Chrome Molly hardened to 42 Rockwell
  • Bolt Coating: Proprietary double layer coating makes them as smooth as glass
  • Firing Pin: Fluted Stainless Steel, .068 diameter tip, Chrome silicon spring
  • Extractor/Ejector: Modified M16 type extractor, Rem 700 style pin ejector
  • Recoil Lug: 416R Stainless parallel sided or tapered. .187” (Rem700 standard) or .300” produced in house and surface ground to .0002” tolerance.
  • Remington 700 LA clone footprint

Note:  Still facility has moved, and markings are now:  Stiller, Shiner, TX.  Otherwise all the same markings and UID code
